VIC005 and VIC006 Pendent Sprinklers are designed for use in automatic sprinkler systems designed per the installation standard (NFPA13). The temperature response is standard response (5mm bulb) and fast response (3mm bulb). The sprinklers feature compact design, different finishes and temperature ratings. The sprinklers body is made of brass die-casting alloy (DZR). The spring seat consists of a springe washer, coated on both sides, and applied with Teflon tape.
K Factor gpm/(psi)1/2 (L3/min(bar)1/2) 5.6 (80)
Nominal Thread Size ½” NPT and ½” BSPT
Max Working Pressure 175 PSI (12bar)
Factory Testing Pressure 500 PSI (35bar)
Min. Operating Pressure 7 PSI (0.5bar)
Finish Brass or Chrome Plated or White Plated Available
Temperature Rating 135°F(57°C) / 155°F(68°C) / 175°F(79°C) / 200°F(93°C) / 286°F(141°C)
